Rear ports of Hikvision DVR with BNC, HDMI, VGA and LAN

Hikvision DS-7104HGHI-M1/T 4 Channel H.265 Pro+ DVR

By HikvisionIn stock

৳3,300

1

Good to know

Specifications

ModelDS-7104HGHI-M1/T
Type4 Channel DVR
Video CompressionH.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264
Video InputsHDTVI / AHD / HDCVI / IP / CVBS
Analog Input4-ch BNC (1.0 Vp-p, 75 Ω), coaxitron supported
HDTVI / AHD / HDCVI Input1080p25, 1080p30, 720p25, 720p30
IP Camera InputUp to 5-ch, up to 2MP
HDMI Output1-ch, up to 1920 × 1080 at 60Hz
VGA Output1-ch, up to 1920 × 1080 at 60Hz
Audio Input / Output1-ch RCA in (4-ch via coaxial cable) / 1-ch RCA out
Two-Way TalkSupported (HDTVI)
Audio CompressionG.711u, 64 Kbps
Bit Rate32 Kbps to 4 Mbps
Sync Playback4-ch
Storage1 SATA, up to 4 TB per disk
USB2 × USB 2.0 (rear panel)
Network Port1 × RJ45 10/100 Mbps
Network FunctionsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP, HTTPS
Power Supply12 VDC, 1.5 A
Power Consumption≤ 10 W (without HDD)
Working Temperature-10 °C to 55 °C
Dimensions200 × 200 × 48 mm
Weight≤ 0.8 kg (without HDD)
Warranty1 Year Manufacturing Warranty

Description

The Hikvision DS-7104HGHI-M1/T is a 4 channel DVR built for reliable day-and-night CCTV recording. H.265 Pro+ compression helps you store more footage on the same hard drive, so you spend less on storage.

It accepts HDTVI, AHD, HDCVI, analog (CVBS) and IP cameras on one recorder. That makes it easy to upgrade an existing setup without replacing every camera. If you are shopping for a Hikvision DVR for a shop, office or home, this model covers the essentials.

Connect it to a monitor over HDMI or VGA, add a hard drive, and you can start monitoring right away. Remote viewing through Hik-Connect lets you check your property from your phone.

Key Features

  • H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 compression: Reduces file size while keeping video clear, so one hard drive stores more days of footage.

  • HDTVI / AHD / HDCVI / IP / CVBS inputs: Works with many camera types, so you can keep your existing cameras and upgrade gradually.

  • 4 analog channels plus up to 5-ch IP camera inputs: Gives you room to expand beyond a basic 4-camera system.

  • Up to 2MP IP camera support (1-ch, up to 5-ch): Lets you add modern IP cameras alongside analog ones.

  • Up to 1080p25/30 input on HDTVI, AHD and HDCVI: Delivers clear Full HD images for faces, vehicles and activity.

  • Audio over coaxial cable and two-way talk (HDTVI): Records sound and lets you speak through compatible cameras without extra audio wiring.

  • HDMI and VGA simultaneous output (up to 1920 × 1080 at 60Hz): Connects to almost any monitor or TV.

  • 1 SATA interface, up to 4 TB per disk: Gives you plenty of local storage for continuous recording.

  • Hik-Connect, DDNS and P2P-style remote access options (TCP/IP, DHCP, PPPoE, UPnP, HTTPS): Lets you view live and recorded video remotely.

  • Compact 200 × 200 × 48 mm body, ≤ 10 W consumption (without HDD): Fits small shelves and racks and keeps running costs low.

Why Choose This Hikvision DS-7104HGHI-M1/T 4 Channel DVR

This 4 channel DVR suits small and medium security setups where reliability and cost matter. H.265 Pro+ compression saves hard drive space, and the multi-format inputs protect your investment in existing cameras.

For everyday use, it records continuously and supports motion detection. It also offers 4-channel synchronous playback, so reviewing an incident is quicker. The compact size and low power use make it easy to install in homes, shops and offices.

If you are comparing a Hikvision DVR with other brands, the wide camera compatibility and the 1-year manufacturing warranty are practical reasons to choose this model.

Best Use Cases

  • Retail shops and showrooms

  • Small offices and workshops

  • Homes and apartments

  • Warehouses and storerooms

  • Upgrading an older analog CCTV system

Compatibility

  • Supported cameras: HDTVI, AHD, HDCVI, analog CVBS and IP cameras (up to 2MP IP, H.265+/H.265/H.264+/H.264).

  • Supported displays: Any monitor or TV with an HDMI or VGA input.

  • Storage: One SATA hard drive, up to 4 TB.

Warranty

1 Year Warranty

Read the warranty policy

Reviews

Frequently asked questions

How many cameras can the Hikvision DS-7104HGHI-M1/T support?

It has 4 analog channels and supports up to 5-ch IP camera inputs.

Which camera types work with this DVR?

HDTVI, AHD, HDCVI, CVBS analog and IP cameras are supported.

What is the maximum hard drive size?

It has one SATA interface and supports up to 4 TB

Can I view the cameras on my phone?

Yes. The DVR supports Hik-Connect, DDNS and other network functions for remote viewing.
