Hikvision DS-7116HGHI-M1/T 16 Channel 1080p Lite DVR

The Hikvision DS-7116HGHI-M1/T is a 16 channel DVR for homes, shops, offices and small businesses. It records 1080p Lite video and uses H.265 Pro+ compression, so you can store more footage on the same hard drive.

If you want a dependable Hikvision DVR for round-the-clock CCTV recording, this Lite Mini 1U model has what most setups need. It has one SATA bay supporting up to 6TB, 16-channel synchronized playback, and two USB 2.0 ports for backup.

Its compact 1U body fits easily on a shelf or in a small rack. You can also order this Hikvision 16 channel DVR in Bangladesh from Geary BD.

Key Features

• 16-channel recording: Connect up to 16 channels on a single recorder. One unit covers a whole building without a second DVR.

• 1080p Lite recording resolution: Records sharp footage for everyday monitoring. The Lite mode keeps the load on storage and bandwidth manageable.

• H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 compression: Supports modern and legacy codecs. Newer compression lets you keep more days of recordings on the same disk.

• 1 x SATA interface, up to 6TB: Gives you a large recording archive from a single drive. That is enough for long retention at typical CCTV bitrates.

• 16-channel sync playback: Reviews all 16 channels at the same time. This helps you trace an incident across several cameras quickly.

• Two-way talk (1-ch RCA): Supports audio communication through the first audio input. You can speak to the camera site when a compatible audio setup is connected.

• Dual-stream support with 96 Mbps total bandwidth: Handles main and sub streams smoothly. This keeps live viewing and recording stable.

• Bit rate from 32 Kbps to 4 Mbps: Lets you balance image quality against storage use for each channel.

• 128 maximum user access: Allows many users to connect to the unit, which suits larger teams and shared monitoring.

• 1 x RJ45 10M/100M Ethernet port: Connects the DVR to your network for remote access and management.

• 2 x USB 2.0 ports: Let you plug in a mouse or a USB drive for backup, so exporting clips is simple.

• Compact 1U mini design (285 × 210 × 48 mm): Saves space on a desk, shelf or rack. It weighs 1.8 kg or less.

• Wide operating range (-10 °C to 55 °C, 10% to 90% humidity): Runs reliably across a wide range of indoor conditions.

Why Choose the Hikvision DS-7116HGHI-M1/T 16 Channel DVR

Hikvision is one of the most recognized names in security recording equipment, and this model is a practical choice for 16-camera setups. It covers the essentials: 1080p Lite recording, H.265 Pro+ compression, a 6TB storage ceiling and synchronized playback on all 16 channels.

It suits buyers who want dependable day-to-day recording without paying for features they will not use. Low power consumption (7 W or less without HDD) helps keep running costs down for a device that stays on 24/7.

Buyers in Bangladesh get a 1-year manufacturing warranty and local support from Geary BD. If you are searching for a Hikvision DVR you can rely on, this model is a strong value pick.

Best Use Cases

• Homes and apartment buildings

• Shops, showrooms and retail stores

• Offices and small businesses

• Warehouses and workshops

• Schools, clinics and other small institutions

Technical Specifications
