Hikvision DS-7116HGHI-M1/T 16 Channel 1080p Lite DVR
৳8,080
Good to know
- 1 Year Warranty
- Cash on delivery available
- Ask on WhatsApp
Specifications
| Brand | Hikvision |
|---|---|
| Model | DS-7116HGHI-M1/T |
| Type | 16 Channel Lite Mini 1U DVR |
| Number of Channels | 16 |
| IP Camera Input | 16 Channel |
| Recording Resolution | 1080p |
| Compression | H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 |
| Bit Rate | 32 Kbps to 4 Mbps |
| Audio Bit Rate | 64 Kbps |
| Dual-Stream | Supported |
| Total Bandwidth | 96 Mbps |
| Two-Way Talk | 1-ch, RCA (2.0 Vp-p, 1 KΩ), using the first audio input |
| Display Resolution (1080p stream) | 1080p Lite / 720p Lite / WD1 / 4CIF / VGA / CIF |
| Display Resolution (720p stream) | 720p / WD1 / 4CIF / VGA / CIF |
| Display Resolution (standard definition stream) | WD1 / 4CIF / VGA / CIF |
| Sync Playback | 16-ch |
| HDD Interface | 1 x SATA |
| Max. Storage | Up to 6TB |
| Ethernet Port | 1 x RJ45 10M/100M self-adaptive |
| Maximum User Access | 128 |
| USB Interface | 2 x USB 2.0 |
| Power Supply | 12 VDC, 2 A |
| Power Consumption | 7 W or less (without HDD) |
| Working Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
| Working Humidity | 10% to 90% |
| Dimensions | 285 × 210 × 48 mm (11.2 × 8.3 × 1.9 inch) |
| Net Weight | 1.8 kg or less |
| Warranty | 1 Year Manufacturing Warranty |
Description
The Hikvision DS-7116HGHI-M1/T is a 16 channel DVR for homes, shops, offices and small businesses. It records 1080p Lite video and uses H.265 Pro+ compression, so you can store more footage on the same hard drive.
If you want a dependable Hikvision DVR for round-the-clock CCTV recording, this Lite Mini 1U model has what most setups need. It has one SATA bay supporting up to 6TB, 16-channel synchronized playback, and two USB 2.0 ports for backup.
Its compact 1U body fits easily on a shelf or in a small rack. You can also order this Hikvision 16 channel DVR in Bangladesh from Geary BD.
Key Features
16-channel recording: Connect up to 16 channels on a single recorder. One unit covers a whole building without a second DVR.
1080p Lite recording resolution: Records sharp footage for everyday monitoring. The Lite mode keeps the load on storage and bandwidth manageable.
H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 compression: Supports modern and legacy codecs. Newer compression lets you keep more days of recordings on the same disk.
1 x SATA interface, up to 6TB: Gives you a large recording archive from a single drive. That is enough for long retention at typical CCTV bitrates.
16-channel sync playback: Reviews all 16 channels at the same time. This helps you trace an incident across several cameras quickly.
Two-way talk (1-ch RCA): Supports audio communication through the first audio input. You can speak to the camera site when a compatible audio setup is connected.
Dual-stream support with 96 Mbps total bandwidth: Handles main and sub streams smoothly. This keeps live viewing and recording stable.
Bit rate from 32 Kbps to 4 Mbps: Lets you balance image quality against storage use for each channel.
128 maximum user access: Allows many users to connect to the unit, which suits larger teams and shared monitoring.
1 x RJ45 10M/100M Ethernet port: Connects the DVR to your network for remote access and management.
2 x USB 2.0 ports: Let you plug in a mouse or a USB drive for backup, so exporting clips is simple.
Compact 1U mini design (285 × 210 × 48 mm): Saves space on a desk, shelf or rack. It weighs 1.8 kg or less.
Wide operating range (-10 °C to 55 °C, 10% to 90% humidity): Runs reliably across a wide range of indoor conditions.
Why Choose the Hikvision DS-7116HGHI-M1/T 16 Channel DVR
Hikvision is one of the most recognized names in security recording equipment, and this model is a practical choice for 16-camera setups. It covers the essentials: 1080p Lite recording, H.265 Pro+ compression, a 6TB storage ceiling and synchronized playback on all 16 channels.
It suits buyers who want dependable day-to-day recording without paying for features they will not use. Low power consumption (7 W or less without HDD) helps keep running costs down for a device that stays on 24/7.
Buyers in Bangladesh get a 1-year manufacturing warranty and local support from Geary BD. If you are searching for a Hikvision DVR you can rely on, this model is a strong value pick.
Best Use Cases
Homes and apartment buildings
Shops, showrooms and retail stores
Offices and small businesses
Warehouses and workshops
Schools, clinics and other small institutions
Warranty
1 Year Warranty
Read the warranty policyReviews
Frequently asked questions
How many cameras can the Hikvision DS-7116HGHI-M1/T support?
It is a 16 channel DVR, so it supports up to 16 channels on one recorder.
What is the maximum hard drive size for this Hikvision DVR?
It has one SATA bay and supports a hard drive of up to 6TB
What recording resolution does the DS-7116HGHI-M1/T support?
It records at 1080p (Lite), and also supports 720p Lite, WD1, 4CIF, VGA and CIF display resolutions.
Which video compression formats does it use?
It supports H.265 Pro+, H.265 Pro, H.265, H.264+ and H.264. H.265 Pro+ helps save storage space on long recordings.
